drylin® T miniature guide carriage TWE-04

1 of 2

drylin® T adjustable low profile linear carriage of the series 04
Robust type
With manual clearance adjustment on the carriage
High corrosion resistance through cathodic dip coating
Material: Housing die cast zinc, iglidur® J slider

Item no.

TWE-04-12

size

04-12

Floating bearing

none

A [mm]

The drylin TWE-04 is an adjustable element with high corrosion resistance, thanks to its high-quality cathodic dip painting. It offers an easy way to adjust the height clearance and the lateral clearance. A screwdriver with 3 mm cutting edge width can be used on the right side of the drylin TWE-04, to adjust the height clearance as required. The left side of the drylin TWE-04 also allows for individual adjustment of the lateral clearance. By simple handling with the screwdriver, the lateral clearance can be can be adjusted to ensure an optimal result and smooth movement.

Certificates and standards
